China Mud Pump BW160 Stable Mud Pump For Small Drilling Rig
Drilling Rig Mud Pump Product description
BW-160 Mud Pumps is equipped with drilling rigs to drill holes with mud. During drilling mud pump pumps slurry to the hole to provide coat to the wall, to lubricate the drilling tools and to carry the rock debris up to the ground. It is applied to geological core drilling and prospecting drilling with depth less than 1000 meter.
Drilling Rig Mud Pump parameter
| Model |
BW-160 |
Input power(Kw) |
5.7kw or 8HP |
| Type |
single urn twin-action triplex piston |
Suction pipe diameter(mm) |
50 |
| Stroke (mm) |
85 |
Dicharge pipe diameter |
32-40 |
| Liner diameter(mm) |
95 |
Mass (kg) |
250 |
| Displacement (l/min) |
160 |
Diamensions(L×W×H) |
1300×980×980 |
| Pressure(Mpa): |
1.3 |
|
Drilling Rig Mud Pump Function:
Mud pump is used with drilling rigs in rotary drilling. It continuously supply fluids to the drilling hole bottom and cycle back to the hole opening with functions of:
A. Cool the heat as the tools turn against rocks and soil at high speeds
B. Lubricate the drilling, extend the lifespan for the drilling tools.
C. Flush the cuttings out from the hole
D. Providing hydrostatic force to strength the drilling wall.
Application of mud pump
1. The dam body of earth dam and earth rock dam in the river channel of reservoir, the cracks and loose layer of dam foundation, and the grouting of cement mortar for karst cave and fault water blocking.
2. The grouting of mortar and anchor rod in bolt shotcreting support engineering.
3. Grouting of cement mortar in tunnel engineering.
4. Grouting of cement mortar for diaphragm wall.
5. The mortar pouring at the junction of highway and bridge.
6. High level or long-distance transportation of other high viscosity solid-liquid mixtures.
Jinzhou Shitan Machinery Equipment Co., Ltd. Main Products：
Pneumatic Drilling Rig / Air Drilling Rig（ST-180, ST-200, ST-260, ST-300, ST-350, ST-400, ST450, ST-450, ST-500, ST-600, ST-800 and other Pneumatic water well drilling Rigs.）, Crawler Water Well Drilling Rig / Trailer Mounted Drilling Rig / Water Well Drilling Rig / Hydraulic Borewell Machine / Hard Rock Drilling Equipment / Diamond Core Drill Rig / Geological Drilling Rig / Soil Testing Drilling Rig / Portable Water Well Drilling Rig（ST-30，ST-50，XY-1A, XY-1B, XY-2, XY-2B, GK180, GK200, GY150, GY200 and 30 impact drill rig, ZLJ series tunnel drilling rig and other geological drilling machines）Crawler Track Undercarriage, Drilling Mud Pump（BW150,BW160,BW200,BW250,BW850 series Drilling mud pumps）, Drilling Air Compressor, Water Well Drill Bits（PDC Drill Bit， Tricone Bit， DTH Button Bit）, Water Well Drill Pipe, Drilling Rig Spare Parts( drilling rods , drilling rods joint , casing pipe, casing coupling, core tube, core tube coupling, lifters, automatic drop hammer, sampler, SPT tool, wrench fork, pad fork, lock joint), Track Transporter
OEM / ODM can accept. Good quality, professional after-sales service, welcome to order
